TNi-W4-WH

Tessen Install Series

TNi-W4-WH

The TNi-W4 delivers professional audio output and versatility within a compact, wall mount speaker enclosure. The TNi-W4 - 4 inch passive enclosure - features 4 power tappings ranging from 1.5W - 30W and can be connected to 70V/100V or 8 ohm low impedance lines. Equipped with euroblock and M4 screw terminals, The TNi-W4 offers a wide array of connections within a single unit. With solid steel, multi-angle bracket included, The TNi-W4 comes with all essential installation components.

Features

  • 100V Power Options
    30W, 15W, 6W, 3W
  • 70V Power Options
    15W, 7.5W, 3W, 1.5W
  • Frequency Response (-10)
    80Hz > 20KHz
  • Frequency Response (-3)
    125Hz - 18KHz
  • LF Driver
    4 Inch Paper
  • HF Driver
    1 Inch
  • Low Nominal System Impedance
    8 Ohm
  • Power
    45W AES, 180W Peak
  • Max SPL (1M) (Peak)
    111 dB SPL
  • Sensitivity (1W/1M)
    88 DB SPL
  • Recommended Amplifer
    80-160W @ 8 Ohms
  • Horiz. Dispersion Angle 1000Hz
    90°
  • Vertical Dispersion Angle 1000Hz
    80°
  • Input Connector
    EUROBLOCK AND M4 TERMINALS
  • Link Connector
    EUROBLOCK AND M4 TERMINALS
  • Mounting Bracket
    ADJUSTABLE STEEL BRACKET INCLUDED
  • Unit Dimensions (Hwd)
    295 X 145 X 222MM, 11.6" X 5.7" X 8.7"
  • Unit Weight
    2.8KG, 6.2 LBS
  • Main Construction Material
    ABS PLASTIC
  • Grille
    WHITE, CIRCULAR STEEL MESH
  • Finish
    White

Installation Speaker System

The HH TNi range offers exceptional installation sound, with a variety of models to suit different sizes of space and power requirements. Options include ceiling and wall mount speakers, available in both white and black to match any aesthetic in your venue. All models feature wide frequency responses, controlled directivity, and excellent vocal clarity to suit a wide range of settings from music venues to retail stores.

For the complete system solution these speakers work great when combined with HH M Series amplifiers and MZ Series zone controllers.
