The HH TNi-4030 cabinet is an ultra-compact full range loudspeaker in the Tessen Installation Range. It is designed to provide maximum performance in its class and be visually unobtrusive It is designed primarily for fixed install use.
Features
Carton Dimensions (Hwd)
465 x 320 x 150mm, 18.3" x 12.6" x 5.9"
Packed Weight
7.9Kg, 17.4 lbs
Unit Weight
3.2Kg/pc, 7.1 lbs/pc
Unit Dimensions (Hwd)
410 x 105 x 120mm, 16.1" x 4.1" x 4.7"
Mounting Bracket
2 x M8 mounting points for optional HH-BRK10 (sold separately)
Linking Bracket
2 x Mounting points for optional HH-LC3 linking bracket
Link Connector
4 Pole Weatherproof connector (IP68)
Cabinet
Injection Moulded
Finish
Black, White finish options available
System Type
4 X 3" Fullrange passive speaker
Frequency Response (-10)
85Hz - 20kHz
Frequency Response (-3)
150Hz - 18kHz
Sensitivity (1W/1M)
92dB
Max SPL (1M) (Peak)
112dB
Power
400W PEAK, 200W CONTINUOUS, 100W RMS
Impedance
8 Ohm
Input Connector
4 pole weatherproof connector (IP68) (one connector included)
